Wear-Resistant Silicone Conductive Spray Ink for Long-Life Electronic Contacts

Product Details

Place of Origin: Guangdong, China

Brand Name: KangLiBang

Certification: ROHS，SGS

Payment & Shipping Terms

Minimum Order Quantity: 1KG

Price: $10-$100

Packaging Details: 1KG/BOTTLE

Delivery Time: 5-7 work days

Payment Terms: T/T

Get Best Price

Contact Now

Specifications

Description

Specifications

Highlight:
                                                                              wear-resistant silicone conductive ink, long-life electronic contact spray, silicone based conductive ink spray


Description

Wear-Resistant Silicone Conductive Spray Ink for Long-Life Electronic Contacts

Silicone Rubber Spraying Conductive Coating Ink

Silicone Rubber Spraying Conductive Coating Ink

Product Description

Manufactured through high-temperature vulcanization, this single-part ink is suitable for coating silicone products that demand electrical conductivity. It supports three printing techniques: screen printing, pad printing, and spot printing.

Application

Mainly applied to silicone products that requires electrical conductivity.

Processing

1.Remove all contaminants (impurities, grease, particles, etc.) from the silicone surface by cleaning.
2. Refrigerated ink must be brought back to room temperature before use. If the ink is overly thick during application, adjust its viscosity with odorless kerosene to suit screen, pad, or spot printing.
3. Allow the ink to rest for 10–30 minutes in a dust-free area. After full solvent evaporation, curing occurs.
4. Vulcanize by heating at 180–200℃ for 10–20 minutes.
5. Use aviation kerosene as a diluent. For spot printing, the ink-to-thinner ratio is 1:2. For screen printing, the ratio is 1:0.2.
6. The resistance is approximately 100 Ω.
All physical data are provided for reference only.

Attention

1. The product should be sealed and stored at 0-10°C, and the storage period is three

months. When the product has passed the storage period, it can be further used after

the technical test.

2. The product should be stirred evenly and completely.

3. Printing must be done in a suitable environment. It is recommended to keep the

working area free of dust, keep the temperature below 25 ° C and control the

humidity to 60-75%. Too low humidity will easily cause static electricity in the ink,

which in turn may result in a poor printed image.

4. Unused ink should be sealed and refrigerated.

Packing

1KG/Bottle.

Application range:

Wear-Resistant Silicone Conductive Spray Ink for Long-Life Electronic Contacts 0

Wear-Resistant Silicone Conductive Spray Ink for Long-Life Electronic Contacts 1
