Flexible Conductive Spraying Ink for Silicone Rubber Remote Control Buttons

Product Details

Place of Origin: Guangdong, China

Brand Name: KangLiBang

Certification: ROHS，SGS

Payment & Shipping Terms

Minimum Order Quantity: 1KG

Price: $10-$100

Packaging Details: 1KG/BOTTLE

Delivery Time: 5-7 work days

Payment Terms: T/T

Get Best Price

Contact Now

Specifications

Description

Specifications

Highlight:
                                                                              flexible conductive spraying ink, silicone rubber remote control ink, conductive ink for silicone buttons


Description

Flexible Conductive Spraying Ink for Silicone Rubber Remote Control Buttons

Silicone Rubber Spraying Conductive Coating Ink

Silicone Rubber Spraying Conductive Coating Ink

Product Description

Employing high-temperature vulcanization technology, this single-component ink is formulated for use on conductive silicone surfaces. It can be applied using screen printing, pad printing, or dot printing methods.

Application

Mainly applied to silicone products that requires electrical conductivity.

Processing

1.RClean the silicone substrate, removing dirt, grease, particles, and similar residues.
2. Bring refrigerated ink to ambient temperature before opening. If the ink feels too thick during application, thin it with odorless kerosene to achieve a workable viscosity for screen, pad, or spot printing.
3. In a dust-free setting, allow the ink to sit for 10–30 minutes. After the solvent evaporates completely, the material cures.
4. Perform vulcanization by heating at 180–200℃ for 10–20 minutes.
5. Suitable thinners are aviation kerosene. For spot printing, dilute at 1 part ink to 2 parts thinner; for screen printing, use 1 part ink to 0.2 parts thinner.
6. The resistance value is approximately 100 Ω.
The above physical data are provided for reference purposes only.

Attention

1. The product should be sealed and stored at 0-10°C, and the storage period is three

months. When the product has passed the storage period, it can be further used after

the technical test.

2. The product should be stirred evenly and completely.

3. Printing must be done in a suitable environment. It is recommended to keep the

working area free of dust, keep the temperature below 25 ° C and control the

humidity to 60-75%. Too low humidity will easily cause static electricity in the ink,

which in turn may result in a poor printed image.

4. Unused ink should be sealed and refrigerated.

Packing

1KG/Bottle.

Application range:

Flexible Conductive Spraying Ink for Silicone Rubber Remote Control Buttons 0

Flexible Conductive Spraying Ink for Silicone Rubber Remote Control Buttons 1
