RoHS Compliant Carbon Conductive Ink for Silicone Keypad & Membrane Switches

Product Details

Place of Origin: Guangdong, China

Brand Name: KangLiBang

Certification: ROHS，SGS

Payment & Shipping Terms

Minimum Order Quantity: 1KG

Price: $10-$100

Packaging Details: 1KG/BOTTLE

Delivery Time: 5-7 work days

Payment Terms: T/T

Get Best Price

Contact Now

Specifications

Description

Specifications

Highlight:
                                                                              RoHS compliant carbon conductive ink, conductive ink for silicone keypad, membrane switch conductive ink


Description

RoHS Compliant Carbon Conductive Ink for Silicone Keypad & Membrane Switches

Silicone Rubber Spraying Conductive Coating Ink

Silicone Rubber Spraying Conductive Coating Ink

Product Description

This conductive ink relies on high-temperature vulcanization technology. Being a one-component system, it adheres to silicone surfaces requiring conductivity. It is compatible with silk screening, pad printing, and dot printing processes.

Application

Mainly applied to silicone products that requires electrical conductivity.

Processing

1.Clean the silicone surface to remove any impurities, oils, particles, or other foreign matter.
2. After taking the ink out of refrigeration, let it come to room temperature before use. If the ink is too viscous, add odorless kerosene to obtain a consistency appropriate for screen, pad, or dot printing.
3. In a dust-free environment, let the ink sit for 10–30 minutes. Cure it once the solvent has fully evaporated.
4. Bake at 180–200℃ for 10–20 minutes to achieve vulcanization.
5. The thinner can be aviation kerosene. For dot printing, dilute at 1:2 (ink:thinner); for screen printing, dilute at 1:0.2.
6. The resistance value is roughly 100 Ω.
These physical data are for reference only.

Attention

1. The product should be sealed and stored at 0-10°C, and the storage period is three

months. When the product has passed the storage period, it can be further used after

the technical test.

2. The product should be stirred evenly and completely.

3. Printing must be done in a suitable environment. It is recommended to keep the

working area free of dust, keep the temperature below 25 ° C and control the

humidity to 60-75%. Too low humidity will easily cause static electricity in the ink,

which in turn may result in a poor printed image.

4. Unused ink should be sealed and refrigerated.

Packing

1KG/Bottle.

Application range:

RoHS Compliant Carbon Conductive Ink for Silicone Keypad & Membrane Switches 0

RoHS Compliant Carbon Conductive Ink for Silicone Keypad & Membrane Switches 1
